Balloon Catheters



Pantera LEO Non Compliant High Pressure Balloon

Empowered with the proven Pantera key design elements, the Pantera LEO Non Compliant High Pressure Balloon is specifically designed for post dilatation of stents and dilatation of hard coronary lesions.

High Pressure Balloon

High Nominal (NP: 14 atm) and Rated Burst Pressures (RBP: 20 atm*) provide the force needed to perform adequately in post-dilatation of stents and dilatation of hard lesions.

*18 atm for ø 4.5/5.0 mm

Non Compliant

The lowest compliance in class ensures controlled minimal growth up to high pressures without any dog-boning effect.

Shortest balloon shoulders

The extra short balloon shoulders enable accurate angioplasty and reduce longitudinal balloon growth to avoid vessel trauma outside the treatment area.

Product specifications

0.018"	Lesion entry profile
145 cm	Usable catheter length
2.0F	Proximal shaft diameter
2.6F (ø 2.0 – 3.75 mm) 2.7F (ø 4.0 – 5.0 mm)	Distal shaft diameter
5F (min. I.D. 0.056")	Guiding catheter
